CPU + Chipset

• Intel® Core™ i3-7020U processor (14nm, 2.3GHz, DDR4-2133MHz, 3MB Smart Cache, TDP: 15W)

Display

• 35.56cm (14.0”) HD (1366X768) 16:9 panel, 3.6mm

Memory

• 4GB Dual channel DDR4 RAM

• Two 260 pins SODIMM sockets, support DDR4 2133MHz (Real operation frequency depends on CPU)

• Expandable memory up to 32GB, depends on 4GB/8GB/16GB SODIMM Module

Video Controller

• Intel® HD Graphics 620

– Dynamic frequency

– Intel Dynamic Video Memory Technology

– Microsoft DirectX® 12 compatible

Storage

• 1TB HDD, 6.35cm (2.5″), 5400rpm, 7mm

Keyboard

• Multi languages A4 size isolated keyboard with Bengali font (Bangladesh Layout)

• Built in touch pad with Microsoft PTP multi-gesture and scrolling function

Sound System

• High Definition Audio

• Built in array microphone

• Built in two speakers

I/O Ports

• 1 x USB 2.0 port

• 1 x USB 3.0 (USB3.1 Gen 1) port (Type A)

• 1 x USB 3.0 (USB3.1 Gen 1) port (Type C)

• 1 x external VGA port

• 1 x HDMI output port (with HDCP)

• 1 x Headphone jack

• 1 x Microphone jack

• 1 x RJ-45 LAN port

• 1 x DC-in jack

Card Reader

• 6-in-1 Card reader

– MMC / RSMMC

– SD / mini SD / SDHC / SDXC

Slots

• Two M.2 Card slots

– 1st for WLAN Combo M.2 2230 Card with PCIe and USB interface (A Key)

– 2nd for M.2 SSD 2280 Card with SATA / PCIe Gen3x4 interface (M Key)

Communication

• Built in 10/100/1000Mb Base-TX Ethernet LAN

• Intel® Dual Band Wireless-AC 3168, 1×1 AC + BT4.2 M.2 2230

• 1.0M HD video camera

Power

• Full Range AC adapter, AC in 100~240V, 50~60Hz, DC output 19V 2.1A, 40W

• Removable 4 cells Smart Lithium-Ion battery pack, 31WH

• Battery life: 400 minutes

Security

• Security (Kensington® Type) Lock Slot

• Intel® PTT for system without Hardware TPM

Operating System

• Free DOS

(Genuine Windows on request)

•Supported Linux

Dimension

• 340(W) x 243.5(D) x 22.2 (H)mm (Height excluded battery area)

• 1.8kg, including Barebone and 31WH Battery
